DAMPER ACTUATOR(CM)

The damper actuator(CM) is unified product perfectly as compact components such as motor, reducer, limit switch, overload torque switch, current transmitter, balancing relay, manual handle device and total control box etc.

The repairing and management are very easy and also it has high reliability, therefore it is motor driving equipment used for an control driving items, boiler, incinerator, burner for combustion driving control or damper for pressure control and valve control etc.

DAMPER ACTUATOR(DMR)

The Damper Actuator(DMR) is compactly assembled by a motor, reducer, manual handle ,opening transmitter, limit switch and torque switch for overload. The 12 type ranging from 10kgm to 3,000kgm are standard and are used in large machines and exact operation is available.

Even if under-bad conditions such as high location, high temperature and much dust, the damper actuator attached to a damper or valve is able to be operated by remote control and is indispensable for factories using the latest machines.

Acting as a servo-control by receiving the signal of a controller or computer , the damper actuator is used in saving energy and cost reduction by controlling the temperature, pressure and flow rate.

The Damper Actuator is superior to a pneumatic and hydraulic devices in various type such as energy spending, maintenance and reliability. As a result , a great many of our actuators have been used for several years in iron and steel field, cement plants , nonferrous metal plants, chemical plants, thermal power stations and others.
